Sawdust Dryer
Processing capacity:1.9-76t/h Cylinder capacity:
9-285m³
Application:sawdust, wood chips, wood flour, wood shavings, etc.
Chat Online Free QuotationEmail us (sales@sinoftm.com),we will reply to you within 24 hours
Application:sawdust, wood chips, wood flour, wood shavings, etc.
Chat Online Free QuotationEmail us (sales@sinoftm.com),we will reply to you within 24 hours
The sawdust dryer uses a screw conveyor to continuously add the wet sawdust into the drying tube. In the transportation and dispersion of the high-speed hot gas flow, the water in the wet material is evaporated to obtain a powdery or granular dry product.
The dryer equipment has strong adaptability to materials and can dry various materials, and the equipment operation is simple and reliable. According to different processing materials, it can be divided into coal dryer, sand dryer, slag dryer, gypsum dryer, lignite dryer, sawdust dryer, etc. Users can choose the machine according to their own needs.
The output humidity can be controlled to 0.5-1% or below according to your requirements.
Inquire DetailsThe sawdust is sent to the hopper by a belt conveyor or bucket elevator, and then enters the feeding end through the feeding pipe through the feeding machine of the hopper. The material is added from the higher end, and the heating medium enters from the lower end, and is in countercurrent contact with the material. When the wet material moves forward in the cylinder, it directly or indirectly receives heat from the heating medium, so that the wet material can be dried, and then sent out through a belt or screw conveyor at the discharge end. In addition, dust collectors can also be used to reduce dust in the drying system.
The heat source used in the dryer is mainly the combustion products for various combustion products,
such as LPG, HFO, natural gas, coal, electric energy, etc. At the same time, the selection of the
heat source of the dryer also affects the operating cost. Therefore, when selecting the heat source
of the dryer, it is necessary for customers to follow the local conditions, the safety of the heat
source, environmental protection, the quality requirements of the materials .
Note:
Temperature control selection: (Manual Control / Automatic Control)
Generally controlled by fuel quantity, you can choose PLC automatic control or manual control.
The thermal efficiency is 80% to 90%. The new internal structure strengthens heat conduction of dispersed materials, and eliminates the sticking phenomenon of the inner wall of the cylinder.
Since the heating mode is easy to control, the temperature inside the cylinder and the heat transfer rate of the partition wall can be kept relatively stable.
The cylinder of the dryer is made of steel material, which has the characteristics of high hardness and high toughness.
The dryer system has good sealing performance, and is equipped with a complete dust removal device, with little dust spillage and a good operating environment.
Model | Shell rotation speed
(r/min) |
Ball load (t) |
Feeding size (mm) |
Discharging size
(mm) |
Capacity (t/h) |
Motor power (kw) |
Total weight (t) |
Ф900×1800 | 36-38 | 1.5 | <20 | 0.075-0.89 | 0.65-2 | 18.5 | 5.85 |
Ф900×3000 | 36 | 2.7 | <20 | 0.075-0.89 | 1.1-3.5 | 22 | 6.98 |
Ф1200×2400 | 36 | 3 | <25 | 0.075-0.6 | 1.5-4.8 | 30 | 13.6 |
Ф1200×3000 | 36 | 3.5 | <25 | 0.074-0.4 | 1.6-5 | 37 | 14.3 |
Ф1200×4500 | 32.4 | 5 | <25 | 0.074-0.4 | 1.6-5.8 | 55 | 15.6 |
Ф1500×3000 | 29.7 | 7.5 | <25 | 0.074-0.4 | 2-5 | 75 | 19.5 |
Ф1500×4500 | 27 | 11 | <25 | 0.074-0.4 | 3-6 | 110 | 22 |
Ф1500×5700 | 28 | 12 | <25 | 0.074-0.4 | 3.5-6 | 130 | 25.8 |
Ф1830×3000 | 25.4 | 11 | <25 | 0.074-0.4 | 4-10 | 130 | 34.5 |
Ф1830×4500 | 25.4 | 15 | <25 | 0.074-0.4 | 4.5-12 | 155 | 38 |
Ф1830×6400 | 24.1 | 21 | <25 | 0.074-0.4 | 6.5-15 | 210 | 43 |
Ф1830×7000 | 24.1 | 23 | <25 | 0.074-0.4 | 7.5-17 | 245 | 43.8 |
Ф2100×3000 | 23.7 | 15 | <25 | 0.074-0.4 | 6.5-36 | 155 | 45 |
Ф2100×4500 | 23.7 | 24 | <25 | 0.074-0.4 | 8-43 | 245 | 56 |
Ф2100×7000 | 23.7 | 26 | <25 | 0.074-0.4 | 12-48 | 280 | 59.5 |
Ф2200×4500 | 21.5 | 27 | <25 | 0.074-0.4 | 9-45 | 280 | 54.5 |
Spec./m
(Dia.×Length) |
Shell Cubage
(m³) |
Capacity
(t/h) |
Φ1.2×8.0
|
9.0
|
1.9~2.4
|
Φ1.2×10
|
11.3
|
2.4~3.0
|
Φ1.5×12
|
21.2
|
4.5~5.7
|
Φ1.5×14
|
24.7
|
5.3~6.6
|
Φ1.5×15
|
26.5
|
5.7~7.1
|
Φ1.8×12
|
30.5
|
6.5~8.1
|
Φ1.8×14
|
35.6
|
7.6~9.5
|
Φ2.2×12
|
45.6
|
9.7~12.2
|
Φ2.2×14
|
53.2
|
11.4~14.2
|
Φ2.2×16
|
60.8
|
13.0~16.2
|
Φ2.4×14
|
63.3
|
13.5~16.9
|
Φ2.4×18
|
81.4
|
17.4~21.7
|
Φ2.4×20
|
90.4
|
19.3~24.1
|
Φ2.4×22
|
99.5
|
21.2~26.5
|
Φ2.6×24
|
127.4
|
27.2~34.0
|
Φ3.0×20
|
141.3
|
30.1~37.7
|
Φ3.0×25
|
176.6
|
37.7~47.1
|
Φ3.2×25
|
201
|
42.9~53.6
|
Φ3.6×28
|
285
|
60.8~76.0
|
Technical parameters of indirect heat dryer:
Shell diameter ×shell Length Items |
Inside diameter of outer shell (mm) |
Inside diameter of inner shell (mm) |
Shell cubage (m³) |
Φ1.5×15m | 1500 | 500 | 20.27 |
Φ1.5×17m | 22.97 | ||
Φ1.5×19m | 25.68 | ||
Φ1.8×21m | 1800 | 650 | 35.91 |
Φ1.8×23m | 39.33 | ||
Φ1.8×25m | 42.75 | ||
Φ2.2×21m | 2200 | 800 | 58.10 |
Φ2.2×23m | 63.61 | ||
Φ2.2×25m | 69.15 |
Hot models: Φ2.4×18, Φ2.2×16, Φ1.8×12
